Specifications

• Platform: AMD
• Chipset: AMD B550
• Socket: AM4
• Form factor: Micro-ATX
• Supported CPU generations: AMD Ryzen 5000, 5000G, 4000G, 3000, and 3000G Series
• Memory type: DDR4
• Memory slots: 4 X DIMM
• Maximum memory: 128 GB
• Memory speed support: Up to DDR4-4733 MT/s (OC)
• Expansion slots: 1 × PCIe 4.0/3.0 x16; 1 × PCIe 3.0 x16 (x4); 1 × PCIe 3.0 x1
• PCIe version: PCIe 4.0
• M.2 slots: 2 × M.2: M2A_CPU supports SATA + up to PCIe 4.0 x4/x2 (CPU-dependent); M2B_SB supports SATA + PCIe 3.0 x2
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek 1GbE
• Rear I/O: 4 × USB 3.2 Gen 1, 4 × USB 2.0, DVI-D, HDMI, PS/2, 1GbE, 3 audio jacks
• Audio: Realtek 7.1-channel High Definition Audio CODEC
• BIOS flashback: Q-Flash Plus
• RGB/ARGB headers: 2 × addressable LED headers, 2 × RGB LED headers, 1 × CPU cooler RGB header
• Power connectors: 1 × 24-pin ATX, 1 × 8-pin CPU
• Features: Smart Fan 5; RGB Fusion 2.0; anti-sulfur resistor design
