Specifications

• Platform: AMD
• Chipset: AMD B650
• Socket: AM5
• Form factor: ATX (30.5 cm × 24.4 cm)
• Supported CPU generations: AMD Ryzen 9000, 8000, and 7000 Series
• Memory type: DDR5
• Memory slots: 4 X DIMM
• Maximum memory: 192 GB
• Memory speed support: Up to DDR5-7600+ MT/s (OC)
• Expansion slots: 1 × PCIe 4.0 x16 (x16 or x8/x4, CPU-dependent); 1 × PCIe 4.0 x16 (x4); 2 × PCIe 4.0 x1
• PCIe version: PCIe 5.0 (M.2), PCIe 4.0 (expansion)
• M.2 slots: 2 × M.2 (1 × up to PCIe 5.0 x4, 1 × PCIe 4.0 x4; CPU-dependent)
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek 2.5GbE
• Rear I/O: 3 × USB 3.2 Gen 2 Type-A, 1 × USB 3.2 Gen 2 Type-C, 2 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 Type-A, DisplayPort, HDMI, M.2 Key E slot, 2.5GbE, 5 audio jacks, optical S/PDIF, BIOS FlashBack button
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
• BIOS flashback: BIOS FlashBack
• RGB/ARGB headers: 3 × Addressable Gen 2 headers, 1 × Aura RGB header
• Power connectors: 1 × 24-pin ATX, 1 × 8-pin CPU
• Features: Q-LED Core; SafeSlot Core+; OptiMem II; USB4 header
