Specifications

• Platform: AMD
• Chipset: AMD B650
• Socket: AM5
• Form factor: ATX (30.5 cm × 24.4 cm)
• Supported CPU generations: AMD Ryzen 9000, 8000, and 7000 Series
• Memory type: DDR5
• Memory slots: 4 X DIMM
• Maximum memory: 256 GB
• Memory speed support: Up to DDR5-7200+ MT/s (OC)
• Expansion slots: 2 × PCIe x16 (x16/x4 with Ryzen 9000/7000); 1 × PCIe 3.0 x1
• PCIe version: PCIe 4.0
• M.2 slots: 2 × M.2 PCIe 4.0 x4
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek RTL8125BG 2.5GbE, Wi-Fi 6E, Bluetooth 5.3
• Rear I/O: 1 × USB 20Gbps Type-C, 3 × USB 10Gbps Type-A, 4 × USB 5Gbps Type-A, DisplayPort, HDMI, Wi-Fi antenna connectors, 2.5GbE, audio jacks, Flash BIOS button
• Audio: Realtek ALC897 7.1-channel High Definition Audio
• BIOS flashback: Flash BIOS Button
• RGB/ARGB headers: 2 × JARGB_V2 headers, 2 × JRGB headers
• Power connectors: 1 × 24-pin ATX, 2 × 8-pin CPU
• Features: EZ Debug LED; M.2 Shield Frozr; AMD EXPO support
