Specifications

• Platform: Intel
• Chipset: Intel B760
• Socket: LGA 1700
• Form factor: Micro-ATX (24.4 cm × 24.4 cm)
• Supported CPU generations: Intel Core 14th, 13th, and 12th Gen; Pentium Gold; Celeron
• Memory type: DDR5
• Memory slots: 4 X DIMM
• Maximum memory: 192 GB
• Memory speed support: Up to DDR5-7800+ MT/s (OC)
• Expansion slots: 1 × PCIe 5.0 x16; 1 × PCIe 4.0 x16 (x4); 2 × PCIe 4.0 x1
• PCIe version: PCIe 5.0
• M.2 slots: 2 × M.2 PCIe 4.0 x4
• SATA ports: 4 X SATA 6Gb/s
• Networking: Intel 2.5GbE, Wi-Fi 6E, Bluetooth 5.3
• Rear I/O: 1 × USB 3.2 Gen 2x2 Type-C, 1 × USB 3.2 Gen 2 Type-A, 2 × USB 3.2 Gen 1 Type-A, 1 × USB 3.2 Gen 1 Type-C, 4 × USB 2.0 Type-A, DisplayPort, HDMI, Wi-Fi antenna connectors, 2.5GbE, 5 audio jacks, BIOS FlashBack button
• Audio: ROG SupremeFX S1220A 7.1 Surround Sound High Definition Audio CODEC
• BIOS flashback: BIOS FlashBack
• RGB/ARGB headers: 3 × Addressable Gen 2 headers, 1 × Aura RGB header
• Power connectors: 1 × 24-pin ATX, 1 × 8-pin CPU, 1 × 4-pin CPU
• Features: M.2 Q-Latch; PCIe Slot Q-Release; Q-LED; SafeSlot; pre-mounted I/O shield
