Specifications

• Platform: Intel
• Chipset: Intel B860
• Socket: LGA 1851
• Form factor: ATX (30.5 cm × 24.4 cm)
• Supported CPU generations: Intel Core Ultra Series 2 processors
• Memory type: DDR5
• Memory slots: 4 X DIMM
• Maximum memory: 256 GB
• Memory speed support: Up to DDR5-9200 MT/s (OC)
• Expansion slots: 1 × PCIe 5.0 x16; 2 × PCIe 4.0 x16 (x1)
• PCIe version: PCIe 5.0
• M.2 slots: 3 × M.2 (1 × PCIe 5.0 x4, 2 × PCIe 4.0 x4)
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek 2.5GbE, Wi-Fi 7, Bluetooth 5.4
• Rear I/O: 1 × USB4 Type-C, 2 × USB 3.2 Gen 2 Type-A, 4 × USB 3.2 Gen 1, 4 × USB 2.0, DisplayPort, HDMI, Wi-Fi antenna connectors, 2.5GbE, optical S/PDIF, 2 audio jacks
• Audio: Realtek 7.1-channel High Definition Audio CODEC
• BIOS flashback: Q-Flash Plus
• RGB/ARGB headers: 3 × addressable RGB Gen 2 headers, 1 × RGB header
• Power connectors: 1 × 24-pin ATX, 2 × 8-pin CPU
• Features: PCIe EZ-Latch Plus; M.2 EZ-Latch; Smart Fan 6; GIGABYTE Control Center
