Specifications

• Platform: AMD
• Chipset: AMD B650
• Socket: AM5
• Form factor: Micro-ATX (24.4 cm × 22.1 cm)
• Supported CPU generations: AMD Ryzen 9000, 8000, and 7000 Series
• Memory type: DDR5
• Memory slots: 2 X DIMM
• Maximum memory: 96 GB
• Memory speed support: Up to DDR5-8000+ MT/s (OC)
• Expansion slots: 1 × PCIe 4.0 x16 (lane width CPU-dependent); 2 × PCIe 4.0 x1
• PCIe version: PCIe 5.0 (M.2), PCIe 4.0 (expansion)
• M.2 slots: 2 × M.2 (1 × up to PCIe 5.0 x4, 1 × PCIe 4.0 x4; CPU-dependent)
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek 2.5GbE
• Rear I/O: 2 × USB 3.2 Gen 2 Type-A, 2 × USB 3.2 Gen 1 Type-A, 4 × USB 2.0 Type-A, VGA, HDMI, 2.5GbE, 3 audio jacks, BIOS FlashBack button, PS/2
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
• BIOS flashback: BIOS FlashBack
• RGB/ARGB headers: 2 × Addressable Gen 2 headers, 1 × Aura RGB header
• Power connectors: 1 × 24-pin ATX, 1 × 8-pin CPU
• Features: 5X Protection III; Q-LED Core; Q-Slot; M.2 heatsink
