Specifications

• Platform: AMD
• Chipset: AMD B550
• Socket: AM4
• Form factor: Micro-ATX (24.4 cm × 24.4 cm)
• Supported CPU generations: AMD Ryzen 5000, 4000G, and 3000 Series
• Memory type: DDR4
• Memory slots: 4 X DIMM
• Maximum memory: 128 GB
• Memory speed support: Up to DDR4-4400+ MT/s (OC)
• Expansion slots: 1 × PCIe 4.0/3.0 x16; 2 × PCIe 3.0 x1
• PCIe version: PCIe 4.0
• M.2 slots: 2 × M.2: M2_1 PCIe 4.0/3.0 x4 + SATA; M2_2 PCIe 3.0 x4
• SATA ports: 4 X SATA 6Gb/s
• Networking: Realtek RTL8111HN 1GbE, Wi-Fi 5, Bluetooth 4.2
• Rear I/O: 4 × USB 3.2 Gen 1 Type-A, 2 × USB 2.0 Type-A, DisplayPort, HDMI, VGA, PS/2, Wi-Fi antenna connectors, 1GbE, 3 audio jacks, Flash BIOS button
• Audio: Realtek ALC892/ALC897 7.1-channel High Definition Audio
• BIOS flashback: Flash BIOS Button
• RGB/ARGB headers: 2 × JRAINBOW headers, 2 × JRGB headers
• Power connectors: 1 × 24-pin ATX, 1 × 8-pin CPU
• Features: EZ Debug LED; A-XMP support; TPM 2.0 header
